Bronze Hex Bushings
SKU
39 Bronze Bushing Series
Bronze threaded fittings are manufactured from smooth-cored castings, designed to provide full flow with minimum restriction. All fittings are individually tested under water to ensure quality. Bronze provides a tighter seal and is easier to install than other metals. Typical applications: Water, plumbing, heating, pneumatic and marine applications, able to resist the harmful effects of corrosion when coming into contact with salt water or fresh water polluted with mineral acids or peaty soils.
Standard Specifications
| Overview | Class 125 (150) for steam, water, gas, oil and air service |
|---|---|
| Materials | ASTM B62-93 (85,5,5,5) C83600 |
| Dimensions | ANSI B 16.15 |
| Threads | ANSI B2.1 or BA 21 and Fed. WW-P-460C, MSS-SP-106, ANSI/ASME B1.20.1 |
| Standard | UL/FM Approved |
| Standard | ISO 9001:2000 |
| Standard | RoHS Compliant |
