Stainless High-Pressure Two-Way Ball Valve 1/2 in FNPT
SKU
H2B-F-8N-S316
High-pressure stainless steel two-way shutoff (on/off) ball valve with lever. 1/2 in FNPT inlet and outlet connections. Maximum pressure: 6000 psi (414 bar).
Specifications
| Body Material | Stainless Steel 316 |
|---|---|
| Maximum Pressure | 6000 psi (414 bar) |
| Handle Type | Lever |
| Flow Co-efficient | 10.00 |
| Inlet End Connection | 1/2 in FNPT |
| Outlet End Connection | 1/2 in FNPT |
| End Connection | Female Thread |
| Orifice (mm) | 12.70 |
| Dimension L (mm) | 90.00 |
| Dimension A (mm) | 162.0 |
| min. d (mm) | 12.70 |
| Dimension H (mm) | 50.80 |
| Dimension S (mm) | 40.00 |
| 60.60 | 41.00 |
