Hankison E7-20 Filter Element
Grade 7 Filter: Air Line. Provides removal of liquid water and oil. Removes solid particulate to 1.0 micron with a 1.0 ppm w/w maximum remaining oil content (established in accordance with CAGI standard ADF400 and is based on 100°F inlet temperature). The first stage of filtration captures larger particles with alternating layers of fiber media and screen. The second stage of filtration coalesces aerosols and captures solid particles with multiple layers of epoxy bonded, blended fiber media.
SKU
$88.00
- Buy 6 for $74.80 each and save 15%
- Buy 10 for $70.40 each and save 20%
Nuvair is an Authorized Hankison® Distributor
Nuvair sells only genuine parts and equipment manufactured by SPX Flow Hankison®. Do not be fooled by cheap aftermarket copies of original Hankison® equipment. Items labeled “replacement” or “alternative” are not manufactured by SPX Flow Hankison®.
Features
| Withstands temperatures to 150°F (66°C) |
| Push-on elements provide simple replacement |
| Piston type seals keeps unfiltered air from bypassing element |
| Stainless steel, corrosion resistant inner and outer core > Low resistance to flow > Seam welded durability |
| Matrix blended fiber media > Large, effective surface area ensures high efficiencies and minimizes pressure drop |
| Coated, closed cell foam sleeve > Resists chemical attack from oils and acids > Ensures high efficiencies by preventing re-entrainment of coalesced liquids |
| Chemically resistant end caps |
| Silicone free |
Specifications
| Model Size | 20 |
|---|---|
| Filter Element Grade | 7: Air Line |
| Model | E7-20 |
| Stainless Steel Element | NO |
| Flow Rating | 60 SCFM |
| Design Temp | 150°F |
| Weight | 0.4 lbs |
