Titan Nitrox Generating System
The Titan is a simple, open model with a complete, state-of-the-art low-pressure/high-pressure (LP/HP) nitrox generating system. It is simple to maintain with easy access to all components. The Titan pumps eniriched air nitrox (EANx) containing 22-40% oxygen with lower costs, less hassles and hazards compared to oxygen blending. You can use the LP or HP compressors independently or together, making the Titan the simplest, most cost-effective nitrox solution available.
SKU
7065 / 7066
Yes
Benefits
- Simple open model
- Easy to maintain with access to all components
- Great for warm tropical areas where production is the main concern
- Because of the large volume tank there is no need for a refrigerated air dryer
- Cost effective
- Available in single phase
- The LP and HP continuous use compressors can be used independently or together to pump nitrox
Features
- 10 CFM nitrox membrane system
- Two (2) O2 analyzers Included
- Electric power (single- and three-phase)
- HP Compressor – pumps air to 4500 psi (310 bar); nitrox to 3600 psi (250 bar)
- LP Compressor – pumps air to 175 psi (12 bar) for membrane supply or surface-supplied diving
- Includes Grade D LP filtration
- Large volume tank is ideal for tropical locations
- Hour meter
Options
- Automatic fill pressure stop
- Automatic LP/HP condensate drains
- Low oil and high temperature shutdown
- HP interstage pressure gauges
- Gas or diesel power with manual or electric start
- Stainless steel package
- Refrigerated air dryer
- ASME Certified or ASME grasshopper tank
Specifications
| Nuvair Titan | R15 / MCH16 (7.5 hp x 2) | R30 / MCH16 (10 hp / 7.5 hp) | |
|---|---|---|---|
| Physical Specifications | Length Width Height Weight |
42 in (107 cm) 89 in (226 cm) 52 in (132 cm) 1250 lb (567 kg) |
42 in (107 cm) 89 in (226 cm) 52 in (132 cm) 1300 lb (590 kg) |
| 220 V / E1 / 60 Hz | 85 A SKU: 7065.1 |
90 A SKU: 7066.1 |
|
| 220 V / E1 / 50 Hz | Special order only | Not available | |
| 208 V / E3 / 60 Hz | 55 A SKU: 7065.2 |
60 A SKU: 7066.2 |
|
| 380 V / E3 / 50 Hz | 27 A SKU: 7065.6 |
29 A SKU: 7066.6 |
|
| 460 V / E3 / 60 Hz | 27 A SKU: 7065.3 |
25 A SKU: 7066.3 |
|
| LP Supply | Capacity @ 175 psi | 23.5 CFM (665 L/min) | 34.8 CFM (985 L/min) |
| Membrane Input | Operating Pressure Optimum Temperature |
90-165 psi (6-11 bar) 110 ±5°F (43 ±3°C) |
90-165 psi (6-11 bar) 110 ±5°F (43 ±3°C) |
| HP Nitrox Compressor | FAD | 8 CFM, FAD (227 L/min) | 10.8 CFM, FAD (306 L/min) |
| RPM | 1350 | 1550 | |
| Air Delivery (SCFM/LPM) | 8-34.8 CFM / 227-985 L/min |
|---|
