Coltri/Nuvair LP300 Rotary Nitrox Generator

The Coltri/Nuvair LP300 rotary nitrox generator consists of an industrial screw-type compressor that delivers air at a pressure of 175 psi (12 bar) to a membrane that separates nitrogen and oxygen up to a maximum percentage of 40% oxygen (O2). The enriched air can be compressed at a pressure of 3365 psi (232 bar) in combination with a high-pressure compressor. The percentage of oxygen obtained at the output can be regulated from 22.4% to 40% thanks to a valve accessible directly on top of the compressor. The oxygen analyzer allows to verify the correct percentage regulated through the appropriate valve. Available in two power configurations: 208-230V/E3/60Hz and 415V/E3/50Hz.

Features

  • Coltri 10 hp rotary screw compressor
  • Three-phase electric motor (50Hz or 60Hz)
  • Pump rated at 32 ACFM (906 L/min) at 175 psi
  • Open marine style 6061 aluminum frame
  • Vertical over/under compressor mounting
  • Hankison LP Three Filter System
    - Coalescing and particles to 1 micron
    - Water and oil vapor to 0.1 micron
    - Oil vapor removal to 0.003 ppm
  • Modulation device
  • Fan Cooled Air/Oil Cooler
  • Manual Compressor Controller
  • Refrigerated Air Dryer

Includes

  • Two (2) oxygen analyzers
  • High-pressure/Low-pressure regualtor with flow meter for oxygen analysis
  • Nuvair 546 food grade lubricant
  • DP gauges, mounting brackets, and auto drains
  • Semi-permeable membrane system
  • 220-volt heater with thermostat
  • Static mixing tyle with inline sensor
  • All hoses and plumbing
  • (25) nitrox scuba tank wraps
  • Installation Manual
  • Daily Operations Manual
  • User Manual

Specifications

Model LP300
Dimensions (L x W x H) 47 x 49 x 34 in
(119.5 x 126 x 85 cm)
Weight 600 lb (272 kg)
208-230 V / E3 / 60 Hz SKU 7060.2-C
415 V / E3 / 50 Hz SKU 7060.6-C
LP Compressor Capacity 32 ACFM @ 175 psi (906 L/min @ 12 bar)
Rated to Supply
 FAD for 40% O2
 FAD for 36% O2
 FAD for 32% O2

11 CFM (311 L/min)
14 CFM (396 L/min)
19 CFM (538 L/min)
Noise 68 dB
