Push-to-Connect Female Branch Swivel Tee: Push Tube x Female Pipe

Composite push-to-connect fittings provide a simple way of connecting tubes to a fitting. Reduce assembly time by eliminating the use of a sleeve and tightening of a nut. Applications: Air, cutting fluids, inert gases, vacuum.

Specifications

Style Tube to Female Pipe
Shape Female Branch Tee Swivel
Body Glass reinfored nylon 6.6
Collar Nylon
Gripping Ring Stainless Steel
D Seal Nitrile
O-Rings Nitrile
Base Nickel plated brass with thread sealant on tapered components and captive seal on parallel threads
Temperature Range +5°F to +155°F
Pressure Range Up to 260 psi depending on tubing
Vacuum Capability 28 inHg
