Air Intake Filter Exposed with Housing: 1 in MNPT

Exposed filter housing for intake filter element SKU 14P. Baked enamel carbon steel housing with 1 in MNPT connection. Filter: 99%+ removal standard to 2 micron. Used on remote intakes for MCH13 and MCH16 gas or diesel compressors. Also used on LP280 membrane system, Nuvair 10 CFM Nitrox System, and Champion R15/R30 intakes.



Housing Material Carbon Steel
Finish Baked Enamel Gray
Connection Type 1 in MNPT
Housing CFM Flow 15
O.D. 4.5 in
Inlet Length 1.5 in
Overall Height 4 in
Weight 1.4 lb
Temperature (continuous) min -15°F (26°C) max 220°F (104°C)
Replacement Element SKU 14P
Element Material Paper
Element CFM Flow 35
Element Efficiency 99%+ removal efficiency standard to 2 micron
Element Surface Area 1.12 sq ft
