Hand Operated 3-Way Vented Toggle Valve

The 816-V toggle valve is used on all paintball panels manufactured by Nuvair. The 816 Series valve is an open or shut valve for air, gas, or liquid lines up to 6000 psi. In the normal or relaxed position the valve is shut and the lever extends straight out. When the lever is tipped in any direction the valve opens. A variety of levers can be connected to the 1/4-20 thread. For example, using an eye bolt as shown, the valve could be operated by a lanyard. In many cases the valve eliminates the need for snap action switches, solenoids, and other complicated devices to open or shut a line based on mechanical action. The 816-V is a 3-way valve that vents downstream pressure when the toggle is released.

SKU

816-V

$156.00

Details

Specifications

Type	Hand Operated 3-Way Vented Open/Close Valve
Maximum Rated Pressure	6000 psi
Maximum Differential Pressure	6000 psi
Inlet Port Size	1/4 in MNPT
Outlet Port Size	1/4 in FNPT
Outlet Pressure Rating	6000 psi
Leakage	Bubble tight
Weight	9.2 oz (260 g)
Overall Length	4.5 in
Hex Diameter	1.38 in
Minimum Temperature	-15ºF (-26ºC)
Body Material	Anodized Aluminum
Internal Materials	Brass Stainless
Seal Materials	Kel-F Viton
Flow Coefficient (Cv)	0.05 (equals 0.07 in orifice)

Typical Applications

Test panels where fast, accurate, hand control of pressure is desired
Gas supply interlocks such as protective doors on charging stations
Component testing
Process industry control
Charging stations where it is desirable to have the supply shutoff if operator releases control
