Hand Load Reducing Regulator: 6000 psi In MNPT > 0–250 psi Out FNPT
$195.00
Anodized aluminum hand load reducing regulator with maximum rated pressure of 6000 psi (414 bar). Outlet pressure range: 0–250 psi (0–17 bar). Outlet pressure rating: 250 psi (17 bar). Non-vented.
SKU
969-NV
The model 969 is a small, economical piston type spring loading regulator. The poppet assembly is contained in a cartridge with internal filtration for easy in-field changing. The regulator is non-venting. It is suitable for either gas or liquid service.
Specifications
| Type | Hand load reducing regulator |
| Special Features | Economical Non-vented Single outlet |
| Maximum Rated Pressure | 6000 psi (414 bar) |
| Outlet Pressure | 0–250 psi (0-17 bar) |
| Outlet Pressure Rating | 250 psi (17 bar) |
| Inlet Port Size | 1/4 in MNPT |
| Outlet Port Size | 1/4 in FNPT |
| Flow coefficient (Cv) | 0.06 (equals 0.07 in orifice) |
| Outlet Pressure Variation with Inlet Pressure | 20 psi rise/1000 psi inlet drop |
| Leakage | Bubble Tight |
| Weight | 11 oz (310 g) |
| Overall Length | 4.5 in (11.4 cm) |
| Hex Diameter | 1-3/8 in |
| Minimum Temperature | -15°F (-26°C) |
| Body Material | Anodized Aluminum |
| Internal Materials | Brass Stainless |
| Seal Materials | Kel-F Viton |
Typical Applications
- Component testing
- Air tank fill stations to eliminate need of low pressure compressors and storage
- Firefighting air stations to provide tire inflating air
- Instrumentation and calibration panels
- Process industry control
- Aircraft service carts to eliminate need for low pressure compressor
- Low pressure air to operate high pressure air operated valves
