Stainless High Temperature Needle Valve 1/4" FNPT
SKU
GB1F-4N-G-S316
Union bonnet needle valve for high temperature service. Rated to 1200°F. 1/4 in FNPT inlet and outlet connections.
Specifications
| Body Material | Stainless Steel 316 |
|---|---|
| Flow Co-efficient | 6.30 |
| Temperature Rating | -65°F to 1200°F (-54°C to 648°C) |
| Applications | Handling corrosives, high temperature service, radioactive and hot condensate |
| Stem Packing | Graphite |
| Inlet End Connection | 1/4 in FNPT |
| Outlet End Connection | 1/4 in FNPT |
| End Connection | Female Pipe Thread |
| Orifice (mm) | 4.00 |
| Dimension L (mm) | 52.4 |
| Dimension L1 (mm) | 26.2 |
| Dimension L2 (mm) | 23.0 |
| Dimension C (mm) | 32.6 |
| Dimension C2 (mm) | 25.4 |
| Dimension D (mm) | 27.8 |
| Dimension D1 (mm) | 32.6 |
| Dimension E (mm) | 11.5 |
| Dimension E1 (mm) | 11.5 |
| Dimension F (mm) | 45 |
| Dimension G (mm) | 15.1 |
| Dimension H Straight (mm) | 77.8 |
