Stainless Phenolic Handle Needle Valve 1/4 in FNPT
$127.50
Integral bonnet needle valve with phenolic handle. 1/4 in FNPT inlet and outlet connections. Stainless steel.
SKU
NV3F-4N-K-S316
Specifications
| Body Material | Stainless Steel 316 |
|---|---|
| Pressure Rating | 5000 psi (345 bar) @ 100°F (38°C) |
| Flow Co-efficient | 0.73 |
| Temperature Rating | -65°F to 600°F (-54°C to 315°C) |
| Inlet End Connection | 1/4 in FNPT |
| Outlet End Connection | 1/4 in FNPT |
| End Connection | Female Pipe Thread |
| Orifice (mm) | 6.30 |
| Dimension L (mm) | 56.00 |
| Dimension L1 (mm) | 28.00 |
| Dimension L2 (mm) | 28.00 |
| Dimension C2 (mm) | 28.00 |
| Dimension D (mm) | 13.50 |
| Dimension F1 (mm) | 50.00 |
| Dimension G (mm) | 20.00 |
| Panel Hole Drill | 0.79 in (20.00mm) |
