MCH22 / MCH30 / MCH36 Open Vertical

SKU
8042 / 8044 / 8051

The Open Vertical MCH22, MCH30 and MCH36 compressors are designed for high use in hot, humid conditions and are rated for continuous duty use up to 6000 psi (414 bar). Equipped with the MCH22, MCH30 or MCH36 four-stage compressor block with a charging rate up to 26.4 SCFM (748 L/min). Purchase, maintenance and operation costs are significantly lower than similar sized compressors in the marketplace.

Features

  • Open configuration for easy access and cool running
  • Operation panel with the following functions:
    - Start/stop button
    - "Dial-a-pressure" automatic shutdown
    - Condensate test button
    - High temperature display
    - Automatic shutdown for high temperature and low oil
    - Phase control (proper rotation) recognition
    - Wrong voltage recognition
    - Hour meter
    - Stage and oil pressure gauges
  • Low pressure oil pump, filter and oil level sight gauge
  • Large stainless steel interstage cooling tubes with large condensate separators
  • Dual filter fitration 60,000 cu ft
  • 6000 psi (414 bar) manimum pressure
  • Grade E breathing air filtration
  • Interstage pressure gauges
  • Four (4) fill whips
  • Electric motor
  • Stainless steel intercoolers

Options

  • Visual CO and moisture indicator
  • Audible and visual CO and high temperature alarm with shutdown
  • Can be upgraded to any size of filtration
  • CO, CO2 and moisture analyzer
  • 7000 psi (482 bar) upgrade
  • Refrigerated air dryer

Specifications

Model Open Vertical MCH22 Open Vertical MCH30 Open Vertical MCH36
Fill Time* Approx. 5 min Approx. 4 min Approx. 3 min
Charging Rate* 14 SCFM (396 L/min) 21 SCFM (596 L/min) 26.4 SCFM (748 L/min)
Motor Single or three-phase electric Three-phase electric Three-phase electric
230 V / E1 / 60 Hz 46 A 10 hp (7.5 kW)
SKU: 8051.1**
N/A
230 V / E3 / 60 Hz 28 A 10 hp (7.5 kW)
SKU: 8051.2**
31 A 15 hp (11 kW)
SKU: 8042.2**
48 A 20 hp (15 kW)
SKU: 8044.2**
400 V / E3 / 50 Hz 17 A 10 hp (7.5 kW)
SKU: 8051.6
18 A 15 hp (11 kW)
SKU: 8042.6
29 A 20 hp (15 kW)
SKU: 8044.6
460 V / E3 / 60 Hz 17 A 10 hp (7.5 kW)
SKU: 8051.3**
16 A 15 hp (11 kW)
SKU: 8042.3**
25 A 20 hp (15 kW)
SKU: 8044.3**
RPM 880 1100 1300
Max Operating Pressure 6000 psi (414 bar) 6000 psi (414 bar) 6000 psi (414 bar)
Number of Stages 4
Number of Fill Hoses 4
Condensate Drain Automatic
Sound Level @ 3 Meters 76 dB
Dimensions (L x W x H) 41.75 x 31.9 x 61 in (106 x 81 x 155 cm)
Dimensions w/Dryer (L x W x H) 42 x 31.9 x 74 in (107 x 81 x 188 cm)
Weight 826 lb (375 kg) 900 lb (408 kg) 915 lb (415 kg)
Lubrication Pressurized Oil Lubrication, Capacity 4.5 qt
Air Quality DIN 3188 - CGA Grade E - NFPA 1500 - EN12021

*Based on 80 cu ft cylinder from 500 to 3000 psi.
**Contact a salesperson for information on 50 Hz compressors not listed.
