Air/Nitrogen 4-Tank Horizontal Storage Rack
Nuvair 4-tank air/nitrogen horizontal racks are made from heavy duty steel with a two-bank manifold system, one HP-HP regulator, and one 2.5 in regulated fill gauge included. Horizontal frame is stackable. Optional fill/distribution panel available. All racks are powder coated blue; other colors available upon request. Other racks can accommodate 1, 2, 3, 4, 6, 8, 9, 12 or 16 tanks; our custom racks can meet any requirement. Certified frames are also available. Unless otherwise stated, air/nitrogen storage tanks are sold separately.
SKU
Yes
Specifications
The 4-tank horizontal storage rack is equipped with:
- (1) High Pressure-High Pressure Regulator
- (1) 2-1/2 in Regulated Fill Gauge
- (2) Banks with Gauges, Isolation Valves and Stainless Steel Tube Manifold
- Optional Fill/Distribution Panel (adds 40 lb [18 kg] to total weight)
- Optional (4) High Pressure Storage Tanks with CGA347 valves
| SKU | Tank Capacity |
Configuration | Dimensions / Included Storage Tanks |
Total Air Storage Capacity |
Approximate Total Weight |
|---|---|---|---|---|---|
| FR-NUVTR-H4 | 4 | Frame Only | 66 L x 52 W x 14 H in with fill/distribution panel 63 L x 46 W x 14 H in without fill/distribution panel |
N/A | 150 lb (68 kg) |
| NUVTR-H4-4500 | 4 | Frame & Air Tanks | Includes (4) 4500 psi storage tanks | 1748 cu ft (49 m³) |
772 lb (350 kg) |
| NUVTR-H4-4500-N | 4 | Frame & Nitrogen Tanks | Includes (4) 4500 psi storage tanks | 1748 cu ft (49 m³) |
772 lb (350 kg) |
| NUVTR-H4-5000 | 4 | Frame & Air Tanks | Includes (4) 5000 psi storage tanks | 1884 cu ft (53 m³) |
840 lb (381 kg) |
| NUVTR-H4-6000 | 4 | Frame & Air Tanks | Includes (4) 6000 psi storage tanks | 2042 cu ft (58 m³) |
944 lb (428 kg) |
* Custom racks are fabricated at our California production facility. Please contact the sales team for estimated lead times.
