MCH13 / MCH16 Vertical Electric
SKU
8060 / 8060-TPS / 8061 / 8061-TPS
This continuous-duty compressor delivers 8.4-11.3 SCFM (238-320 L/min). Available with TPS (Tropical Plus Superdry) filtration, the Vertical Electric is available in four models. Compact in design with a powder coated frame that has all equipment inset, the Nuvair Vertical Electric is unsurpassed in quality, reliability and price.
Features
- Standard or Troprical Plus Superdry (TPS) filtration
- 5000 psi (345 bar)
- TPS (Tropical Plus Superdry) option delivering 6000 psi (414 bar) available with the MCH16 version - Three cylinder, three stage, air-cooled
- Hour meter
- Interstage pressure gauges
- Two (2) large condensate separators
- Large stainless steel interstage cooling tubes
- Splash lubricated with oil sight gauge
- Automatic condensate drains
- NEMA 4X enclosed electric box
- Low oil shutdown switch
- High temperature switch set at 350°F
- Pressure shutdown switch
- Double auto drain MCH13-16 vertical open 110V control
Options
- Water cooling [ More Information ]
- Stainless steel package
- Dial-a-pressure shutdown
- Electronic moisture monitor
- SEP-15 & CAN-35 air water filtration system 6000 psi
- Remote fill panel
- Frame mounted with storage tanks below for paintball use
- Digital CO monitor
- Visual CO/moisture indicator
Specifications
| Model | MCH13 | MCH13 TPS | MCH16 | MCH16 TPS |
|---|---|---|---|---|
| Fill Time* | ~11 minutes | ~11 minutes | ~9 minutes | ~9 minutes |
| Motor | Single or three-phase electric | Single or three-phase electric | Three-phase electric | Three-phase electric |
| Charging Rate* | 8.4 SCFM (238 L/min) | 8.4 SCFM (238 L/min) | 11.3 SCFM (320 L/min) | 11.3 SCFM (320 L/min) |
| CFM FAD | 7 CFM (200 L/min) | 7 CFM (200 L/min) | 9.4 CFM (266 L/min) | 9.4 CFM (266 L/min) |
| Motor | 5 hp (4 kW) | 5 hp (4 kW) | 7.5 hp (5.5 kW) | 7.5 hp (5.5 kW) |
| 208-230V/E1/60Hz | 25 A SKU 8060.1 |
25 A SKU 8060.1-TPS |
34 A SKU 8061.1 |
34 A SKU 8061.1-TPS |
| 208-230V/E3/60Hz | 14 A SKU 8060.2 |
14 A SKU 8060.2-TPS |
20 A SKU 8061.2 |
20 A SKU 8061.2-TPS |
| 380-415V/E3/50Hz | SKU 8060.6 | SKU 8060.6-TPS | SKU 8060.6 | SKU 8060.6-TPS |
| 440-480V/E3/60Hz | 7 A SKU 8060.3 |
7 A SKU 8060.3-TPS |
10 A SKU 8061.3 |
10 A SKU 8061.3-TPS |
| Max Working Pressure | 5000 psi (345 bar) | 5000 psi (345 bar) | 5000 psi (345 bar) | 6000 psi (414 bar) |
| RPM | 1200 | 1200 | 1450 | 1450 |
| Number of Stages | 3 | 3 | 3 | 3 |
| Filtration† | 13,000 cu ft @ 80°F | 26,0000 cu ft @ 80°F | 13,000 cu ft @ 80°F | 26,0000 cu ft @ 80°F |
| Condensate Drain | Automatic | Automatic | Automatic | Automatic |
| Fill Pressure Stop | Automatic | Automatic | Automatic | Automatic |
| Dimensions (L × W × H) |
32 × 36 × 45 in (91 × 91 × 114 cm) |
32 × 36 × 45 in (91 × 91 × 114 cm) |
32 × 36 × 52 in (91 × 91 × 132 cm) |
32 × 36 × 52 in (91 × 91 × 132 cm) |
| Net Weight Approximate | 340 lb (186 kg) | 340 lb (191 kg) | 420 lb (191 kg) | 430 lb (195 kg) |
| Lubrication | Splash Lubrication, capacity 1.8 L | |||
| Air Quality | DIN 3188 - CGA Grade E - NFPA 1500 - EN12021 | |||
* Based on 80 cu ft cylinder from 500 to 3000 psi.
†If the compressor is located in an area where there is high humidity and high heat, the life of all filtration elements may be as little as 35% of rated operating capacity.
