MCH13 · MCH16 Water Cooled Compressor
SKU
8019-WC / 8022-WC / 8022-HYD
Water cooled compressors are designed for hot (≤41-133°F · 5-45°C), humid (80% max), and poorly ventilated areas. It is perfect for engine rooms on liveaboards and other vessels. The compressor uses seawater or freshwater for cooling and is great for nitrox or air production. Powered by electric motor or hydraulic drive. Charging rate up to 11.3 SCFM (320 L/min).
All features of the standard MCH13 / MCH16 apply to this product, in addition to the features listed below.
Features
- Cools each stage to within 10°F of water temperature
- First stage copper/nickel heat exchanger
- Second and third stage stainless steel heat exchangers (water coolers)
- All heat exchangers/water coolers have zinc anodes to increase life
- Water flow shutdown switch
- High water temperature shutdown
- Rugged 5000 psi (345 bar) three-stage block
- Pressurized oil lubrication
- 3x condensate separators
- Stainless steel tubing
- Marine grade 6061 aluminum frame
Options
- PLC controller
- Motor control box
- External filtration system (industrial or breathing air quality)
- MCH16 hydraulic pump drive (SKU 8022-HYD)
- Pressure switch
- 3/4" flow switch inline paddle type 7-20 L/min (SKU IWDB20)
- 1" flow switch inline paddle type 8-50 L/min (SKU IWDB25) - Automatic drains (as shown in image)
- Interstage pressure gauges (as shown in image)
- Low oil shutdown switch
- Hour meter
- Visual CO/moisture indicator
- Stainless steel frame
Specifications
| Model | MCH13 Electric | MCH16 Electric | MCH16 Hydraulic |
|---|---|---|---|
| Motor | Single- or three-phase electric | Single- or three-phase electric | Hydraulic |
| Fill Time* | ~11 minutes | ~9 minutes | ~9 minutes |
| Charging Rate* | 8.4 SCFM (238 L/min) | 11.3 SCFM (320 L/min) | 11.3 SCFM (320 L/min) |
| CFM FAD | 7 CFM (200 L/min) | 9.4 CFM (266 L/min) | 9.4 CFM (266 L/min) |
| Power | 5.5 hp (4 kW) Electric | 7.5 hp (5.5 kW) Electric | Hydraulic SKU 8022-HYD |
| 208-230V / E1 / 60 Hz | 24A SKU 8019.1-WC |
35A SKU 8022.1-WC |
N/A |
| 208-230V / E3 / 60 Hz | 14A SKU 8019.2-WC |
22A SKU 8022.2-WC |
N/A |
| 440-460V / E3 / 60 Hz | 7A SKU 8019.3-WC |
11A SKU 8022.3-WC |
N/A |
| 230V / E3 / 50 Hz | 14A SKU 8019.5-WC |
12A SKU 8022.5-WC |
N/A |
| 380-400V / E3 / 50 Hz | 9A SKU 8019.6-WC |
13A SKU 8022.6-WC |
N/A |
| Max Working Pressure | 5000 psi (345 bar) | ||
| Dimensions (L × W × H) |
45 × 21 × 31 in (114 × 53.3 × 78.7 cm) |
||
| Weight | 297 lb (134.7 kg) | ||
*Fill time based on 80 cu ft cylinder from 500 to 3000 psi.
