Nason Temperature Switch 120°F Rising 1/8" MNPT NC
$36.78
SKU
TT-F42B-120R/WL
Fixed set point opens at 120°F on the rise. 6" wire leads. 1/8" MNPT.
Specifications
| Probe Length | 1" |
|---|---|
| Media Connection | 1/8" MNPT |
| Circuit Form | SPST-NC |
| Fixed Set Point | 120°F |
| Set Point Direction | Rising |
| Set Point Tolerance | ±5°F (2.8°C) |
| Maximum External Pressure | 5000 psi |
| Electrical Options | Wire Leads 6" |
| Current Rating | .1A & 3A @ 120VAC | 4A 12 VDC & 24 VDC (gold diffused contacts) |
