Quincy 390/Nuvair MCH36 Electric LP/HP Nitrox System
Complete, state-of-the-art low pressure/high pressure (LP/HP) nitrox generating system. Compressors can be used independently to provide HP or LP air, or together to provide nitrox. Using the latest membrane technology, no volume tank is required. Produces a constant flow of nitrox from 22-40% at 26.4 SCFM (747 L/min).
SKU
7058
Yes
Includes
- Low oil and high temperature automatic shutdown
- HP auto condensate drains
- LP auto condensate drain
- L-Factor AF-531-112 HP filtration
- Diesel model available
- Heavy duty frame with vibration isolated inside frame
- Stainless steel panel
Membrane System
- Two (2) Pro O2 analyzers one with in-line sensor
- Air intake filter and static mixing tube
- Auto thermostatic control
- Nuvair 455 food grade compressor lubricant for breathing air applications
Compressors
- LP Air Filtration: Hankison Series 20
- Auto drains/DP gauges
- Coalescing 1.0 micron
- Fine polishing .01 micron
- Oil vapor removal .003 ppm - LP back-pressure regulator for oxygen percentage adjustment
- Refrigerated dryer and separator
- Supplying Grade D air
- LP Compressor: 20 hp – 69 CFM @ 175 psi (1954 L/min @ 12 bar)
- HP Compressor: 15 hp – 26.4 CFM @ up to 3600 psi (578 L/min @ 250 bar)
- Weight: 2600 lb (1179 kg)
- Physical Dimensions (L x W x H): 80 x 48 x 57 in (203.2 x 121.9 x 144.8 cm)
- 3-phase 208-230, 380-415 or 440-480 V with motor starter and on/off switch.
Motor Options
| 208-230 V / E3 / 50 Hz | 108 A SKU 7058.5 |
| 208-230 V / E3 / 60 Hz | 108 A SKU 7058.2 |
| 380-415 V / E3 / 50 Hz | 60 A SKU 7058.6 |
| 440-480 V / E3 / 60 Hz | 50 A SKU 7058.3 |
| Compressor | |
| LP Compressor | Capacity @ 175 psi: 69 CFM (1954 L/min) |
| HP Compressor | Capacity @ 3600 psi: 24.8 SCFM (702 L/min) |
| Volume Tank Capacity | 60 gal (227 L) |
| Dimensions (L x W x H) | 80 x 48 x 57 in (203 x 122 x 145 cm) |
| Weight | 2600 lb (1179 kg) |
