2019 Coltri Ergo TPS

Mounted in an ergonomically designed powder-coated steel frame, the 2019 Ergo TPS is the newest edition to the Nuvair line of high pressure air compressors. Similar in performance to the Coltri/Nuvair Mini Tech, the Ergo open frame offers easy component access and a reduced footprint for space conscious users.

Available in four models to meet different air delivery needs, the pressure gauge, hour meter and emergency stop button are all mounted to the Ergo's sleek control panel. Pumps up to 11.5 CFM, 13.42 SCFM (380 L/min) at 5000 psi (345 bar). Fills an 80 cu ft scuba cylinder in about 7 minutes.

SKU
8023-TPS / 8024-TPS / 8025-TPS / 8026-TPS
Yes

Features

  • Three-phase electric motor
  • Mounted on an ergonomic powder-coated frame
  • Tri-chem breathing air purification system
  • Disposable purification cartridge
  • Low oil shutdown
  • Interstage pressure gauges
  • Automatic condensate drains
  • Pressure relief valve on all stages
  • Emergency stop
  • Motor starter
  • Hour meter

Options

  • Pressure switch
  • High temperature shutdown
  • Visual carbon monoxide / moisture indicator
  • Gas power
  • Diesel power

Specifications

Model MCH13 MCH16 MCH21 MCH23
Fill Time* ~11 minutes ~9 minutes ~8 minutes ~7 minutes
Charging Rate* 8.4 SCFM
(238 L/min)

11.3 SCFM
(320 L/min)

12.2 SCFM
(345 L/min)
13.4 SCFM
(380 L/min)
CFM FAD 7 CFM
(200 L/min)
9.4 CFM
(266 L/min)
10.3 CFM
(292 L/min)
11.5 CFM
(325 L/min)
230 V / E1 / 60 Hz 5.5 hp
SKU 8023.1-TPS
N/A  N/A  N/A
230 V / E3 / 60 Hz 5.5 hp
SKU 8023.2-TPS
7.5 hp
SKU 8026.2-TPS
10 hp
SKU 8024.2-TPS
10 hp
SKU 8025.2-TPS
380-415 V / E3 / 50 Hz 5.5 hp
SKU 8023.6-TPS
7.5 hp
SKU 8026.6-TPS
10 hp
SKU 8024.6-TPS
10 hp
SKU 8025.6-TPS
440-480 V / E3 / 60 Hz 5.5 hp
SKU 8023.3-TPS
7.5 hp
SKU 8026.3-TPS
10 hp
SKU 8024.3-TPS
10 hp
SKU 8025.3-TPS
Weight 337 lb (153 kg) 360 lb (163 kg)  362 lb (164 kg)  362 lb (164 kg)
Condensate Drain Automatic
Dimensions
(L x W x H)
37 x 23 x 25 in
(94 x 58 x 64 cm)
Number of Fill Hoses 2
Maximum Operating Pressure 5000 psi (345 bar)
Lubrication Oil pump
Air Quality DIN 3188 - CGA Grade E - NFPA 1500 - EN12021

*Based on 80 cu ft cylinder from 500 to 3000 psi.
