Coltri MCH26 / MCH32 Compact

SKU
8036 / 8036-13

The MCH26 / MCH36 Compact filling station utilizes two completely independent compressors for reliability and versatility. Use one compressor to pump air while using the other to pump nitrox using Nuvair's Nitrox Membrane System. Operation is fully automatic and up to four cylinders can be filled simultaneously. The container is lined with a sound reduction material which limits noise. The internal air conveyors ensure excellent cooling.

Features

  • Motor starter
  • Automatic condensate drains
  • Interstage pressure gauges
  • Dial-a-pressure switch
  • Automatic stop
  • Hour meter
  • Sound reducing cabinet
  • External oil sight gauge
  • Low oil shutown
  • High temperature shutdown
  • 5000 psi (345 bar) maximum pressure
  • Grade E breathing air filtration
  • Two (2) fill whips
  • Stainless steel intercoolers

Options

  • Visual CO / moisture indicator
  • Additional filtration

Specifications

Model Compact MCH26 Compact MCH32
Fill Time* Approx. 4.5 min Approx. 3.7 min
Charging Rate* 17.8 SCFM (504 L/min) 21.6 SCFM (612 L/min)
Motor Options Single or three-phase electric Three-phase electric
230 V / E1 / 60 Hz 25 amps SKU: 8036.1-13 N/A
230 V / E3 / 50 or 60 Hz 14 amps SKU: 8036.2-13** 20 amps SKU: 8036.2**
400 V / E3 / 50 Hz 17 amps SKU: 8036.6-13 27 amps SKU: 8036.6
440 V / E3 / 50 or 60 Hz 7 amps SKU: 8036.3-13** 10 amps SKU: 8036.3**
Motor Power 2 x 5.5 hp (4 kW) 2 x 7.5 hp (5.5 kW)
Max. Operating Pressure 5000 psi (345 bar) 5000 psi (345 bar)
RPM 1350 1550
Number of Stages 3 3
Number of Fill Hoses 4 4
Condensate Drain Automatic Automatic
Fill Pressure Stop Automatic Automatic
Sound Level @ 3 Meters 72 dB 75 dB
Dimensions
(L x W x H)
34 x 35 x 53 in
(85 x 89 x 133 cm)
34 x 35 x 53 in
(85 x 89 x 133 cm)
Weight 629 lb (286 kg) 673 lb (306 kg)
Lubrication Splash lubrication, capacity 2 x 1.6 qt
Air Quality DIN 3188 - CGA Grade E - NFPA 1500 - EN12021

*Based on 80 cu ft cylinder from 500 to 3000 psi.

**Part number reflects 60 Hz models. Call to learn about our 50 Hz models.
