MCH22–MCH45 Vertical Silent Touch Compressor
The Nuvair MCH22-MCH45 Silent Touch Series is equipped with an HMI (Human Machine Interface) touchscreen system controller called the Dashboard. The Dashboard allows users to monitor compressor activity, gauge status, and identify alarm events. High volume facilities where sound may be an issue should consider our Enclosed & Silenced line of compressors that deliver up to 32 SCFM (906 L/min) at 6000 psi (414 bar). Unsurpassed in quality, reliability and price, the Enclosed & Silenced package is designed for high use in work areas where noise cannot be tolerated. Available in four models: MCH22-PLC, MCH30-PLC, MCH36-PLC, and MCH45-PLC.
Features
- Enclosed Configuration for Reduced Sound Levels
- Nuvair customized Human Machine Interface (HMI) Touchscreen Control Dashboard
- Dashboard Controls Include:
- Start/Stop Buttons
- Pressure Setpoint
- Condensate Test Purge
- Final Pressure Setting
- Alarm History
- Service Hours
- Gauge Display - Independent Digital Cabinet Temperature Indicator
- Large Stainless Steel Interstage Cooling Tubes with Large Condensate Separators
- Dual filter filtration 60,000 cu ft
- 6000 psi (414 bar) maximum pressure
- Grade E breathing air filtration
- Analog Interstage Pressure Gauges
- Four (4) Fill Whips with Choice of Connections
- Electric Motor
- Stainless Steel Intercoolers
Options
- Visual Carbon Monoxide (CO) and Moisture Indicator
- Nuvair Pro CO (carbon monoxide) Analyzer
- Nuvair Pro H2O (moisture) Monitor
- Filtration Upgrade to 90,000 cu ft
- 7000 psi (482 bar) Upgrade
- Refrigerated Air Dryer
Specifications
| Model | MCH22 Silent Touch | MCH30 Silent Touch | MCH36 Silent Touch | MCH45 Silent Touch |
|---|---|---|---|---|
| Fill Time** | ~5 minutes | ~4 minutes | ~3 minutes | ~2.5 minutes |
| Charging Rate** | 15.8 SCFM (320 L/min) | 20.4 SCFM (577 L/min) | 27 SCFM (764 L/min) | 32 SCFM (906 L/min) |
| CFM FAD | 13.2 CFM (374 L/min) | 17 CFM (481 L/min) | 22.5 CFM (637 L/min) | 26.5 CFM (750 L/min) |
| Motor | Single & three-phase electric | Three-phase electric | Three-phase electric | Three-phase electric |
| 208-230 V / E1 / 60 Hz | 46A 10 hp (7.5 kW) SKU 8052.1-PLC |
N/A | N/A | N/A |
| 208-230 V / E3 / 60 Hz | 28A 10 hp (7.5 kW) SKU 8052.2-PLC* |
31A 15 hp (11 kW) SKU 8043.2-PLC* |
48A 20 hp (15 kW) SKU 8045.2-PLC* |
53.7A 24 hp (18 kW) SKU 8056.2-PLC* |
| 380-415 V / E3 / 50 Hz | 17A 10 hp (7.5 kW) SKU 8052.6-PLC |
18A 15 hp (11 kW) SKU 8043.6-PLC |
29A 20 hp (15 kW) SKU 8045.6-PLC* |
31A 24 hp (18 kW) SKU 8056.6-PLC |
| 440-480 V / E3 / 60 Hz | 17A 10 hp (7.5 kW) SKU 8052.3-PLC* |
16A 15 hp (11 kW) SKU 8043.3-PLC* |
25A 20 hp (15 kW) SKU 8045.3-PLC* |
28.5A 24 hp (18 kW) SKU 8056.3-PLC* |
| Compressor RPM | 1050 | 1250 | 1250 | 1420 |
| Maximum Operating Pressure | 6000 psi (414 bar) | |||
| Number of Stages | 4 | |||
| Number of Fill Hoses | 4 | |||
| Condensate Drain | Automatic | |||
| Sound Level | 70 LpA Measured (dB) | |||
| Dimensions (L x W x H) | 31.9 × 49 × 69 in (81 × 124 × 175 cm) | |||
| Weight | 926 lb (420 kg) | 1126 lb (511 kg) | 1210 lb (549 kg) | 1210 lb (549 kg) |
| Lubrication | Pressure lubrication, capacity 4 L | |||
| Air Quality | DIN 3188 - CGA Grade E - NFPA 1500 - EN12021 | |||
*Part number reflects 60 Hz models. Call to learn about our 50 Hz models.
**Based on 80 cu ft cylinder from 500 to 3000 psi.
