Stainless Braided Hose Series
Starting at $36.35
Stainless steel hose with one layer of stainless steel braid, stainless steel braid collar, and Schedule 40 stainless steel MNPT (MNPT x MNPT) end fittings. Also available: MNPT x FNPT Union fittings ("MF") as indicated. Different hose lengths and sizes available. Working pressure based on hose size and ranges from 796 psi (1/2 in) to 370 psi (1-1/2 in). Manufactured in the United States.
SKU
HSS Series
Specifications
| SKU | Size | Overall Length¹ | Maximum O.D. | Working Pressure² | Maximum Tested Pressure² |
|---|---|---|---|---|---|
| HSS-5012 | 1/2 in (12.7 mm) | 12 in (304.8 mm) | 0.76 in (19.304 mm) | 796 psi (54.8 bar) | 1194 psi (82.3 bar) |
| HSS-5018 | 1/2 in (12.7 mm) | 18 in (457.2 mm) | 0.76 in (19.304 mm) | 796 psi (54.8 bar) | 1194 psi (82.3 bar) |
| HSS-5024 | 1/2 in (12.7 mm) | 24 in (609.6 mm) | 0.76 in (19.304 mm) | 796 psi (54.8 bar) | 1194 psi (82.3 bar) |
| HSS-5036 | 1/2 in (12.7 mm) | 36 in (914.4 mm) | 0.76 in (19.304 mm) | 796 psi (54.8 bar) | 1194 psi (82.3 bar) |
| HSS-5042 | 1/2 in (12.7 mm) | 42 in (1066.8 mm) | 0.76 in (19.304 mm) | 796 psi (54.8 bar) | 1194 psi (82.3 bar) |
| HSS-7512 | 3/4 in (19.05 mm) | 12 in (304.8 mm) | 1.03 in (26.162 mm) | 597 psi (41.2 bar) | 895 psi (61.7 bar) |
| HSS-7518 | 3/4 in (19.05 mm) | 18 in (457.2 mm) | 1.03 in (26.162 mm) | 597 psi (41.2 bar) | 895 psi (61.7 bar) |
| HSS-7524 | 3/4 in (19.05 mm) | 24 in (609.6 mm) | 1.03 in (26.162 mm) | 597 psi (41.2 bar) | 895 psi (61.7 bar) |
| HSS-7536 | 3/4 in (19.05 mm) | 36 in (914.4 mm) | 1.03 in (26.162 mm) | 597 psi (41.2 bar) | 895 psi (61.7 bar) |
| HSS-7542 | 3/4 in (19.05 mm) | 42 in (1066.8 mm) | 1.03 in (26.162 mm) | 597 psi (41.2 bar) | 895 psi (61.7 bar) |
| HSS-1018 | 1 in (25.4 mm) | 18 in (457.2 mm) | 1.32 in (33.528 mm) | 455 psi (31.4 bar) | 682 psi (47.0 bar) |
| HSS-1024 | 1 in (25.4 mm) | 24 in (609.6 mm) | 1.32 in (33.528 mm) | 455 psi (31.4 bar) | 682 psi (47.0 bar) |
| HSS-1036 | 1 in (25.4 mm) | 36 in (914.4 mm) | 1.32 in (33.528 mm) | 455 psi (31.4 bar) | 682 psi (47.0 bar) |
| HSS-1042 | 1 in (25.4 mm) | 42 in (1066.8 mm) | 1.32 in (33.528 mm) | 455 psi (31.4 bar) | 682 psi (47.0 bar) |
| HSS-1212 | 1-1/4 in (31.75 mm) | 12 in (304.8 mm) | 1.63 in (41.402 mm) | 441 psi (30.4 bar) | 661 psi (45.6 bar) |
| HSS-1224 | 1-1/4 in (31.75 mm) | 24 in (609.6 mm) | 1.63 in (41.402 mm) | 441 psi (30.4 bar) | 661 psi (45.6 bar) |
| HSS-1232 | 1-1/4 in (31.75 mm) | 32 in (812.8 mm) | 1.63 in (41.402 mm) | 441 psi (30.4 bar) | 661 psi (45.6 bar) |
| HSS-1248 | 1-1/4 in (31.75 mm) | 48 in (1219.2 mm) | 1.63 in (41.402 mm) | 441 psi (30.4 bar) | 661 psi (45.6 bar) |
| HSS-1248MF | 1-1/4 in (31.75 mm) | 48 in (1219.2 mm) | 1.63 in (41.402 mm) | 441 psi (30.4 bar) | 661 psi (45.6 bar) |
| HSS-1548MF | 1-1/2 in (38.1 mm) | 48 in (1219.2 mm) | 1.91 in (48.5 mm) | 370 psi (25.5 bar) | 555 psi (38.2 bar) |
¹ Overall Length: ±1/8 in per foot.
² Tested @ 70°F (21°C). See Temperature Derating Factors (below).
Temperature Derating Factors: Multiply × Working Pressure
| 200°F | 250°F | 300°F | 350°F | 400°F | 500°F | 600°F | 700°F | 800°F | 900°F |
|---|---|---|---|---|---|---|---|---|---|
| 93.3°C | 121.1°C | 148.9°C | 176.7°C | 204.4°C | 260°C | 315.6°C | 371.1°C | 426.7°C | 482.2°C |
| 0.94 | 0.92 | 0.88 | 0.86 | 0.83 | 0.78 | 0.74 | 0.70 | 0.66 | 0.62 |
