Brass Push-Lock Hose Barb x Female JIC Swivel

SKU

SF Series

Grouped product items
Product Name	Qty
Brass Push-Lock 1/2" Hose x #8 SAE Swivel \| SF8X8 $6.06

Push-lock hose barb - Female JIC/SAE "dual-seat" swivel. HS × FJX/SAE. Allows users to quickly and easily make hose assemblies right on the job site without special tools. Applications include pneumatics, petroleum-base fluids, antifreeze, diesel, and phosphate ester. This "Dual-Seat" Swivel is possible because the 37° JIC Flare and the 45° SAE Flare use the same threads except in the 3/8 in and 3/4 in sizes.

Details

Specifications

SKU	SF8X8
Product Type	Push-Lock Hose Barb
Media	Hydraulic/Pneumatic
Material	Brass
Orientation	Straight
Pressure & Temperature Rating	Hose Dependent
Tube O.D.	1/2 in, 12.7 mm
1 - Thread Type	Push-Lock Barb
1 - Size	-08 (1/2 in)
1 - Thread	0.500 in O.D.
2 - Thread Type	Female JIC/SAE Swivel
2 - Size	-08 (1/2 in)
2 - Thread	3/4 - 16
